Security Barriers
ZKTeco FBL2200 Dual Lane Flap Barrier
50 views
|
SKU: ZK-FBL2200-001
₹185,000
Dual lane flap barrier for high-traffic areas. ZKTeco FBL2200 is a high-security dual-lane flap barrier system designed for efficient pedestrian access control. It features a durable stainless steel body, fast motorized flap operation, and infrared anti-tailgating sensors for enhanced safety. The system supports RFID and biometric integration and ensures smooth bi-directional movement, making it ideal for offices, metro stations, airports, and other high-traffic areas.
Warranty
1 Year Standard
Delivery
Pan India
Installation
Free Setup
Support
24/7 Available
Technical Description :
| Parameter | Specification |
|---|---|
| Model Name | ZKTeco FBL2200 |
| Brand | ZKTeco |
| Type | Dual Lane Flap Barrier Turnstile |
| Barrier Type | Automatic Retracting Flap Gate |
| Material | SS 304 Stainless Steel |
| Lane Type | Dual Lane (can integrate with FBL2000 series) |
| Passage Width | 600 mm per lane |
| Throughput Speed | 25–30 persons/min (RFID) |
| Operation Mode | Bi-directional |
| Drive Mechanism | DC Motorized System |
| Sensor System | Infrared Anti-tailgating Sensors |
| Control Input | RFID / Fingerprint / Access Control System |
| Communication | TCP/IP, RS485 (optional integration) |
| Power Supply | AC 100–240V, 50/60Hz |
| Operating Temperature | -28°C to 60°C |
| Humidity Range | 5% – 80% |
| Emergency Mode | Automatic flap open during power failure |
| Protection Level | Medium Security |
| Installation Type | Floor Mounted |
| MCBF (Life Cycle) | Up to 2 million cycles |
| Weight | Approx. 68–70 kg |
