IN-01A Fingerprint Time Attendance and Access Control Terminal
· 3.0-inch TFT Color
Display
· 3,000 Fingerprint
Capacity
· 10,000 Card Capacity
(Optional ID/IC/HID)
· 100,000 Transaction
Capacity
· TCP/IP, USB Host &
Client, and RS232/485 (Optional Wi-Fi or GPRS)
· Wiegand In & Out
· Built-in Backup
Battery (2000 mAh)
· DC 12V/1.5A Power
Supply
· Dimensions: 210 × 157
× 50 mm
| Type | Time & Attendance with Access Control |
| Attendance Mode | FP + Card |
| Authentication Method | Fingerprint |
| Authentication Method | Password |
| Authentication Method | RFID Card |
| User Capacity | 10000 Users |
| Connectivity | TCP/IP |
| Access Control | Door + Wiegand |
| Power Supply | 12 Volt 2 Amp |
| Screen Size | 2.8 inch |
| Display Type | LCD |
| Connectivity Type | Wired |
| Display Type | Digital |
| Biometric Technology | Facial Recognition |
| Capacity | 3000 |
| Model Name/Number | U Face 402 |
| Language | English |
| Battery Backup | Yes (Optional) |
| Power Source | Battery Operated |
| Power Source | Power Adapter |
| Warranty | 1 Year |
| Communication | RS485 |
| Communication | TCP/IP |
| Transaction Storage | 100000 |
| Operating System Supported | Linux |
| Resolution | 500 DPI |
| Sensor Type | Optical Sensor |
| Brand | ZKTeco |
| Type Of Attandance System | Fingerprint |
Minimum order quantity: 1 Piece
- Remarkable User Experience
- Enhanced Features and Performance.
- Excellent Expandability
- Access Control Interface
Technical Specifications
Fingerprint Capacity : 3000
ID Card Capacity : 10,000 (Optional)
Record Capacity : 100,000
Display : 3 inch TFT Screen
Communication : TCP/IP,USB Host & Client
Standard Functions : Webserver, Work code, SMS, DST, Scheduled-bell, Self-Service Query, Automatic Status Switch, Photo ID,
Access Control Interface : 3rd Party Electric Lock, Door Sensor, Exit Button, Alarm, and Door Bell
Wiegand Singal : Input&Output
Optional Functions : ID/Mifare/HID, External Printer, ADMS, Wi-Fi, GPRS
Software : ZKTime. Net3.0
Power Supply : DC12V 1.5A
Operating Temp : 0 °C- 45 °C
Operating Humidity : 20%-80%
Dimension : 221.7*159.5*42.9mm (Length*Width*Thickness)
